Network Setup 4-97
7. Check the Use Default Values option checkbox to set the Username and Password to factory default
values. The Access Port can get disconnected if the 802.1x authenticator is not configured accordingly.
8. Refer to the Status field for the current state of the requests made from applet. This field displays error
messages if something goes wrong in the transaction between the applet and the switch.
9. Click OK to use the changes to the running configuration and close the dialog.
10.Click Cancel to close the dialog without committing updates to the running configuration.
4.7.1.3 Editing AP Settings
The Edit screen provides a means of modifying the properties of an existing radio. This is often necessary
when the radio’s intended function has changed and its name needs modification or if the radio now needs
to be defined as a detector radio. The Edit screen also enables you to modify placement, channel, and power
settings as well as a set of advanced properties in case its transmit and receive capabilities need to be
adjusted.
To edit a radio’s configuration:
1. Select Network > Access Port Radios from the main menu tree.
2. Click the Configuration tab.
3. Select a radio to edit from the table.
NOTE: 802.1x username and password information is only passed to adopted Access
Ports when the Username and Password are set. Any AP adopted after this does not
automatically receive a username and password.
NOTE: After setting the username and password to factory default settings, the system
must be rebooted before the factory default settings are applied
NOTE: The screen display can vary slightly depending on whether the Access Port radio is
an 802.11b, 802.11bg and 802.11bgn or 802.11a and 802.11an model.
