6-78 Motorola RF Switch System Reference Guide
3. Click the Add button.
4. Define the following information as required for the new transform set.
5. Refer to the Status field for the current state of the requests made from applet. This field displays error
messages if something goes wrong in the transaction between the applet and the switch.
6. Click OK to use the changes to the running configuration and close the dialog.
7. Click Cancel to close the dialog without committing updates to the running configuration.
Name Create a name describing this new transform set.
AH Authentication
Scheme
Select the Use AH checkbox to define the AH Transform Authentication scheme.
Options include:
• None - No AH authentication is used.
• AH-MD5-HMAC - AH with the MD5 (HMAC variant) authentication algorithm.
• AH-SHA-HMAC - AH with the SHA (HMAC variant) authentication algorithm.
ESP Encryption
Scheme
Select the Use ESP checkbox to define the ESP Encryption Scheme. Options
include:
• None - No ESP encryption is used with the transform set.
• ESP-DES - ESP with the 56-bit DES encryption algorithm.
• ESP-3DES - ESP with 3DES, ESP with AES.
• ESP-AES - ESP with 3DES, ESP with AES (128 bit key).
• ESP-AES 192 - ESP with 3DES, ESP with AES (192 bit key).
• ESP-AES 256 - ESP with 3DES, ESP with AES (256 bit key).
ESP Authentication
Scheme
Select the Use ESP checkbox to define the ESP Authentication Scheme. Options
include:
• None - No ESP authentication is used with the transform set.
• MD5-HMAC - AH with the MD5 (HMAC variant) authentication algorithm.
• SHA-HMAC - AH with the SHA (HMAC variant) authentication algorithm.
Mode Define the current mode used with the transform set. The mode is either Tunnel or
Transport.
