Motorola RFS Series System Reference Guide

Switch Security 6-91
a. Select the Seq #/Name.
b. Enter the name of the Transform set used with the Crypto Map.
7. Click OK when completed to save the configuration of the Crypto Map transform set.
6.7.4.5 Crypto Map Interfaces
To review the interfaces currently available to the Crypto Maps or assign an interface:
1. Select Security > IPSec VPN from the main menu tree.
2. Click the Crypto Maps tab and select Interfaces.
3. Refer to the following read-only information displayed within the Interfaces tab.
4. Click the Assign Interface button to assign a Crypto Map to each interface through which IPSec traffic
flows.
Assigning the Crypto Map set to an interface instructs the security appliance to evaluate all the traffic
against the Crypto Map set and use the specified policy during connection or SA negotiation. Assigning
a Crypto Map to an interface also initializes run-time data structures (such as the SA database and the
security policy database). Reassigning a modified Crypto Map to the interface resynchronizes the run-
time data structures with the Crypto Map configuration. Also, adding new peers through the new
sequence numbers and reassigning the Crypto Map does not break existing connections.
NOTE: A Crypto Map cannot get applied to more than one interface at a time. To apply
the same Crypto Map settings to multiple interfaces, create a unique Crypto Map for each
interface.
Name Lists the name of the Crypto Maps available for the interface.
Interface Name Displays the name of the interface through which IPSec traffic flows. Applying the
Crypto Map set to an interface instructs the switch to evaluate all the interface's
traffic against the Crypto Map set and to use the specified policy during
connection or security association negotiation on behalf of traffic protected by
crypto (either CET or IPSec).
