Native Instruments MASCHINE MK3 User Manual

Controls Description
Level Adjusts the level of the signal sent to the Aux 1 or Aux 2 output.
Order If Order is set to Pre, the channel will be fed into Aux 1 or Aux 2
before the Level and Pan settings of the MAIN section on the Audio
page are applied. If Order is set to Post (default setting), the Level
and Pan settings of the main output also affect the signals sent to
the auxiliary outputs.
If MASCHINE is running as a plug-in, the external stereo outputs Ext. 1–16 available in
the Dest. selectors of the AUX 1 and AUX 2 section will correspond to virtual outputs in
your host. This allows you to send auxiliary outputs of individual Sounds or Groups from
MASCHINE to their own mixer channels within your DAW, for example.
Setting Up the Auxiliary Outputs of Sounds and Groups in Mix View
You can also easily set up auxiliary outputs for your Sounds and Groups in MASCHINE’s Mixer:
1. Click the Mix View button on the left of the Arranger to switch from Arrange view to Mix
view:
2. Open the extended view of the Mixer by clicking the down-pointing arrow on the left of the
Mixer:
Audio Routing, Remote Control, and Macro Controls
Audio Routing in MASCHINE
MASCHINE - Manual - 546

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
