Monitoring System Access and Performance
461
ProSecure Unified Threat Management (UTM) Appliance
Figure 271.
The following table explains the fields of the Network Status screen:
View the Router Statistics Screen
 To view the Router Statistics screen:
1. Select Monitoring > System Status > Network Status. The Network Status screen
displays.
2. Click the Show Statistics option arrow in the upper right of the Network Status screen. The
Router Statistics screen displays. (The following figure shows the Router Statistics screen of
the UTM50.)
Table 118. Network Status screen fields
Item Description
LAN (VLAN) Information
For each of the LAN ports, the screen shows the IP address and subnet mask. For more detailed information,
see Table 121 on page 465.
WAN Information
For each of the WAN ports, the screen shows the IP address, subnet mask, and status of the port (UP or
DOWN). For more detailed information, see Table 121 on page 465.
