Macro Reference
388
Vision System FH/FZ5 Series
User’s Manual (Z340)
GetUnitFigur
e
Gets figure data to the
processing unit
Processing unit
control
OK OK OK OK
Reference: X
Details (p.554)
Gosub Operate the specified subroutine
General
instruction
OK OK OK OK
Reference: X
Details (p.556)
Goto
Moves the process to the
statement line with a specified
label
General
instruction
OK OK OK OK
Reference: X
Details (p.558)
Hex$
Converts the value in the
expression to the hexadecimal
value in character string format
String
Operation
OK OK OK OK
Reference: X
Details (p.560)
If Then Else
Controls the process flow
according to the specified
condition
General
instruction
OK OK OK OK
Reference: X
Details (p.562)
If Then Elseif
Else EndIf
Controls the process flow
according to the specified
condition
General
instruction
OK OK OK OK
Reference: X
Details (p.564)
ImageFormat
Gets the image format of the
image in the processing unit
Processing unit
control
OK OK OK OK
Reference: X
Details (p.566)
ImageUpdate
Updates the image input from
the camera
Measurement
control
--- OK OK ---
Reference: X
Details (p.568)
Input# Reads data from the file File Control OK OK OK OK
Reference: X
Details (p.569)
Input$ Reads binary data from the file File Control OK OK OK OK
Reference: X
Details (p.571)
InsertUnit Inserts a processing unit Flow control --- OK OK ---
Reference: X
Details (p.573)
Int
Converts numeric value to
integer value
Arithmetic
Calculation
OK OK OK OK
Reference: X
Det
ails (p.575)
Isfile
Checks the attribute and the
existence of the file
File Control OK OK OK OK
Reference: X
Details (p.577)
ItemCount
Gets the number of useable
processing item types
Control
processing item
--- OK OK ---
Reference: X
Details (p.579)
ItemIdent$
Gets the identification name of
the processing item
Control
processing item
--- OK OK ---
Reference: X
Details (p.580)
ItemInfo
Gets the processing item
information
Control
processing item
--- OK OK ---
Reference: X
Details (p.582)
ItemTitle$ Gets the processing item title
Control
processing item
--- OK OK ---
Reference: X
Details (p.584)
JudgeOut
Sets the output state of the
overall judgement signal
IO Module
Control
--- OK OK OK
Reference: X
Details (p.585)
Kill Deletes a file File Control OK OK OK OK
Reference: X
Details (p.587)
LCase$
Converts an upper case letter to
a lower case letter
String
Operation
OK OK OK OK
Reference: X
Details (p.589)
Left$
Extracts the specified length of
characters from the left side of
character string
String
Operation
OK OK OK OK
Reference: X
Details (p.591)
Command
Name
Function Classification
Unit
Calculat
ion
Macro
Scene
Control
Macro
Commu
nication
Comma
nd
Macro
Unit
Macro
References
