Macro Reference
391
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Right$
Extracts the specified length of
characters from the right side of
character string
String
Operation
OK OK OK OK
Reference: X
Details (p.664)
Rmdir Deletes a directory File Control OK OK OK OK
Reference: X
Details (p.666)
RunOut
Sets the output state of the RUN
signal
IO Module
Control
--- OK OK OK
Reference: X
Details (p.667)
SaveBackup
Data
Saves the system + scene
group 0 data
Data Save/
Load
--- OK OK ---
Reference: X
Details (p.669)
SaveData Saves the data to the controller
Data Save/
Load
--- OK OK ---
Reference: X
Details (p.670)
SaveImage Saves image data
Measurement
control
--- OK OK ---
Reference: X
Details (p.671)
SaveMeasur
eImage
Saves the measurement image
of the processing unit
Processing unit
control
--- --- --- OK
Reference: X
Details (p.673)
SaveScene Saves the scene data
Data Save/
Load
--- OK OK ---
Reference: X
Details (p.675)
SaveSceneG
roup
Saves the scene group data
Data Save/
Load
--- OK OK ---
Reference: X
Details (p.677)
SaveSystem
Data
Saves the system data
Data Save/
Load
--- OK OK ---
Reference: X
Details (p.679)
SaveUnitDat
a
Saves a processing unit
Data Save/
Load
--- OK OK ---
Reference: X
Det
ails (p.681)
SceneCount
Gets the number of scenes that
can be used
Scene control --- OK OK ---
Reference: X
Details (p.683)
SceneDescri
ption$
Gets the scene description Scene control OK --- OK ---
Reference: X
Details (p.684)
SceneGroup
Count
Gets the number of useable
scene groups
Scene group
control
--- OK OK ---
Reference: X
Details (p.686)
SceneGroup
No
Gets the scene group number of
the current scene group
Scene group
control
--- OK OK ---
Reference: X
Details (p.687)
SceneGroup
Title$
Gets the title of the scene group
Scene group
control
--- OK OK ---
Reference: X
Details (p.688)
SceneMaker
$
Gets the scene creator Scene control --- OK OK ---
Reference: X
Details (p.689)
SceneNo
Gets the scene number of the
current scene
Scene control --- OK OK ---
Reference: X
Details (p.691)
SceneTitle$ Gets the scene title Scene control --- OK OK ---
Reference: X
Details (p.692)
ScreenCaptu
re
Saves the capture of the screen Others --- OK OK ---
Reference: X
Details (p.693)
Select Case
Case Else
End Select
Controls the process flow
according to the specified
condition
General
instruction
OK OK OK OK
Reference: X
Details (p.694)
SendData Sends data
IO Module
Control
--- OK OK OK
Reference: X
Details (p.696)
Command
Name
Function Classification
Unit
Calculat
ion
Macro
Scene
Control
Macro
Commu
nication
Comma
nd
Macro
Unit
Macro
References
