Setting up Compax3
192-120100 N16 C3I10T10 - December 2010
97
PC requirements
Recommendation:
Operating system: MS Windows XP SP2 / MS Windows 2000 as from SP4 / (MS Vista)
Browser:
MS Internet Explorer 6.x
Processor: Intel Pentium 4 / Intel Core 2 Duo / AMD Athlon class as from
>=2GHz
RAM memory: >= 1024MB
Hard disk: >= 20GB available memory
Drive: DVD drive
Monitor: Resolution 1024x768 or higher
Graphics card: on onboard graphics (for performance reasons)
Interface: USB
Minimum requirements:
Operating system: MS Windows XP SP2 / MS Windows 2000 as from SP4
Browser: MS Internet Explorer 6.x
Processor: >=1.5GHz
RAM memory: 512MB
Hard disk: 10GB available memory
Drive: DVD drive
Monitor: Resolution 1024x768 or higher
Graphics card: on onboard graphics (for performance reasons)
Interface: USB
 For the installation of the software you need administrator authorization on the
target computer.
Note:
 Several applications running in parallel, reduce the performance and operability.
 Especially customer applications, exchanging standard system components
(drivers) in order to improve their own performance, may have a strong influence
on the communication performance or even render normal use impossible.
 Operation under virtual machines such as Vware Workstation 6/ MS Virtual PC is
not possible.
 Onboard graphics card solutions reduce the system performance by up to 20%
and cannot be recommended.
 Operation with notebooks in current-saving mode may lead, in individual cases,
to communication problems.
Your PC is connected with Compax3 via a RS232 cable (SSK1 (see on page
205)).
Cable SSK1 (see on page 205) (COM 1/2-interface on the PC to X10 on the
Compax3 or via adapter SSK32/20 on programming interface of Compax3H).
Start the Compax3 ServoManager and make the setting for the selected interface
in the "Options Communication settings RS232/RS485..." menu.
In the menu tree under device selection you can read the device type of the
connected device (Online Device Identification) or select a device type (Device
Selection Wizard).
Then you can double click on "Configuration" to start the configuration wizard. The
wizard will lead you through all input windows of the configuration.
Input quantities will be described in the following chapters, in the same order in which you are queried about them by the configuration
wizard.
Connection
between PC and
Compax3
Device Selection
Configuration
