3.87
ENGINE / COOLING SYSTEM
3
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Excessive Smoke and Carbon Buildup
• Excessive piston-to-cylinder clearance
• Wet sumping due to over-full crankcase
• Worn rings, piston, or cylinder
• Worn valve guides or seals
• Restricted breather
• Air filter dirty or contaminated
Low Compression
• Cylinder head gasket leak
• No valve clearance (cam wear)
• Cylinder or piston worn
• Piston rings worn, leaking, broken, or sticking
• Bent valve or stuck valve
• Valve spring broken or weak
• Valve not seating properly (bent or carbon
accu
mulated on sealing surface)
• Rocker arm sticking
Backfiring
• Fouled spark plug or incorrect plug or plug gap
• Exhaust system air leaks
• Valve sticking
• Ignition system faulty: ï€
Spark plug cap cracked / brokenï€
Ignition coil faultyï€
Ignition or kill switch circuit faultyï€
Poor connections in ignition systemï€
Ignition timing incorrectï€
Sheared flywheel key
Cooling System
Overheating
• Low coolant level
• Air in cooling system
• Wrong type/mix of coolant
• Faulty pressure cap or system leaks
• Restricted system (mud or debris in radiator fins
causing
restriction to air flow, passages blocked in
radiator, lines, pump, or water jacket, accident
damage)
• Lean mixture (vents, fuel pump or fuel valve)
• Fuel pump output weak
• Electrical malfunction
• Water pump failure/ Loose impeller
• Thermistor failure
• Cooling fan inoperative or turning too slowly
(perf
orm current draw test)
• Low oil level
• Spark plug incorrect heat range
• Faulty hot light circuit
• Thermostat stuck closed or not opening
completely
• Radiator is missing its internal diverter plate not
allo
wing coolant to flow through entire radiator
Temperature Too Low
• Thermostat stuck open
Leak at Water Pump Weep Hole
• Faulty water pump mechanical seal (coolant leak)
• Faulty pump shaft oil seal (oil leak)
