2.13
MAINTENANCE
2
9923523 - RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Throttle Freeplay Adjustment
Inspection
1. Place the transmission in the P (Park) position.
2. Start the engine, and warm it up thoroughly.
3. Measure the distance the throttle pedal moves before
the
en gine be gins to increase in RPM . Freeplay
should be 1/16” - 1/8” (1.5 - 3 mm).
Adjustment
1. Remove the car go box a ccess panel to ac
cess the
throttle body area.
2. Locate thro ttle ca ble o n the le ft-hand side o f the
thr
ottle body. Slide back the cable adjuster boot.
3. Using an o pen-end wrench, lo osen the a djustment
ja
m nut (A). Using another open-end wrench, move
the cable adjuster (B) until 1/16” to 1/8” (1.5 - 3 mm)
of freeplay is achieved at the throttle pedal.
NOTE: While adj usting, li ght
ly move th e t hrottle
pedal in and out.
4. Re-tighten the jam nut after fina
l adjustment is made.
5. Apply a small am ount of grease to the inside of the
bo
ot and slide it over the cable adjuster to its original
position.
6. Reinstall the cargo box access panel.
Engine and PVT Intake Pre-Filter Service
It is r ecommended that the e ngine and PVT intake pre-
filter b e in spected daily. T he filter sho uld be inspe cted
using the following procedure:
NOTE: T
he engine and PVT inta ke pre-filter is locate d
just above the left-rear wheel fender.
1. Press “IN” on the intak e grill cover
tabs and remove
the pre-filter cover to access the pre-filters.
2. Remove and insp ect the p re-filters. If ne cessary,
cle
an with soapy water and dry with compressed air.
3. Reinstall the dry pre-filter s an
d inst all the pr e-filter
cover.
Press In Tabs
Pre-filter Cover
