FRONT BRAKE PADS
Pad Removal
1. Elevate and support front of vehicle.
2. Remove the front wheel.
3. Loosen the pad adjuster screw 2-3 turns.
4. Remove and disca rd the upp er and lower calip er
mo
unting bolts and remove the caliper from the front
hub.
NOTE: When remo ving c aliper, us e c are not to
da
mage brake line . Supp ort c aliper so t o avo id
kinking or bending brake line.
5. Push caliper pis ton into c
aliper bore slowly using a
C-clamp or locking pliers with pads installed.
NOTE: Brake fluid will be fo rced t hrough
compe
nsating p ort in to ma ster c ylinder fluid
reservoir whe n pist on is p ushed ba ck into c aliper.
Remove excess fluid from reservoir as required.
6. Push the mounting bracket inward and the slip outer
b
rake pad out between the bracket and caliper body.
7. Remove the inner pad from the bracket and caliper.
CAUTION
Use care when supporting vehicle so that it
does not tip or fall.
Severe injury may occur if machine tips or falls.
