PROPSHAFT U-JOINT SERVICE
Disassembly
1. Remove internal or e xternal snap ring from bearing
caps.
NOTE: If yoke or bearing is removed, cross bearing
mus
t be re placed. Note orient ation of grea se fitting
and mar k inner and o uter yo ke f or c orrect r e-
positioning during installation.
2. Support inn er yoke as sh own an d d rive ou ter yoke
d
own (bearing cap out) with a soft face hammer.
3. Support U-joint in vise as shown and drive inner yoke
down to re
move remaining bearing caps.
4. Force U-jo int cro ss to one side an d lift o ut of in ner
yo
ke.
Always wear eye protection.
