9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Starter Solenoid Bench Test
Test the st art so lenoid by powering th e so lenoid using
battery vo ltage fo r a
maximum of 5 seconds . Wit h the
solenoid energized, resistance should read about 0 - 0.5
Ohms b etween ter minals (A) an d (B). If r esistance
measurement is ou t of specif ication, replace the starter
solenoid.
Starter Solenoid Operation
To energize the Starter Solenoid the following must occur:
• The brake must be applied to provide a ground
p
ath via the Orange wire.
• The key switch must be turned to the “start”
position to pr
ovide 12V power via the Green /
White wire.
• Once the pull-in coil is energized, the solenoid
pro
vides a current path for 12V power to reach the
starter motor.
