DRIVEN CLUTCH SERVICE
Exploded View
Clutch Disassembly / Inspection
1. Remove d riven c lutch from t he tr ansmission in put
shaft.
2. Mark the p osition of the clutch she aves b efore
d
isassembly or use th e X’s o n th e shea ves for
reference. T his a ids in re assembly an d m aintains
clutch balance after reassembly.
Stationary
Moveable
Inner
Compression Spring
Outer
Retaining
Spring Retainer
Ring
Spacer
Spring Retainer
Secondary Sheave
Secondary Sheave
Washer
Bolt
36 ft. lbs. (48.5 Nm)
Wear eye protection when removing snap ring to
prevent serious personal injury.
Use caution when removing, the snap ring
pressure is loaded by the compression spring.
