2.20
MAINTENANCE
9923523 - RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Exhaust - Spark Arrestor
Periodically clean spark arrestor to remove accumulated carbon.
1. Allow engine and exhaust system to completely cool.
2. Remove the retaining screw, washer and spark arrestor from the end of the silencer.
3. Use a non-synthetic brush to clean the arrestor screen.
4. Inspect the screen for wear and damage. Replace if needed.
5. Reinstall the arrestor and torque the screw to 40 i
n. lbs. (4.5 Nm).
WARNING
Do not clean spark arrestor immediately after the
engine has been run, as the exhaust system
becomes very hot. Serious burns could result from
contact with the exhaust components. Allow
components to cool sufficiently before proceeding.
Wear eye protection and gloves.
Never run the engine in an enclosed area. Exhaust
co
ntains poisonous carbon monoxide gas that can
cause loss of consciousness or death in a very
short time.
40 in. lbs.
(4.5 Nm)
18 ft. lbs.
(24.5 Nm)
Gaskets and Seals -
Replace Each Time Component is Removed
18 ft. lbs.
(24.5 Nm)
