7.12
FINAL DRIVE
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
PROPSHAFT SERVICE
Removal / Installation
1. Remove both seats and the engine service panel as
outlined in Chapter 5.
2. Disconnect the negative (-) battery cable.
3. Raise and support vehicle and remove the left-hand
r
ear wheel.
4. From th e right-hand front wheel well, locate the
pr
opshaft roll pin. Use the Roll Pin Removal Tool (PN
2872608) to r emove the ro ll pin fro m th e fro nt
gearcase.
5. Remove the o uter clutch cover, drive belt and drive
clutch as outline
d in Chapter 6.
6. Disconnect the ha rness con nector at the bra ke
switch
. Remove the (2) screws securing the brake line
junction block and move the jun ction block towards
the left-hand frame rail.
7. Remove the g ear sele ctor ca p a nd remove the
reta
ining screw and handle.
8. Remove the Torx screws retaining the center console
to
access the propshaft.
Serious injury may result if machine tips or falls.
Be sure machine is secure before beginning this
service procedure. Wear eye protection when
removing bearings and seals.
Roll Pin Removal Tool (PN 2872608)
Screw
Torx Screws
Cap
Torx Screws
Torx Screws
Handle
