Polaris 2012 RANGER RZR 570 INTL User Manual

10.11
ELECTRICAL
10
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Rider Information Display
The rider information display is located in the instrument
cluster. All segments will light up for 1 second at start-up.
NOTE: If the instrument cluster fai
ls to illuminate, a
battery ov er-voltage may ha ve occurred a nd t he
instrument c luster may ha ve shut off to pr otect the
electronic speedometer.
1. Ve
hicle Sp eed Display - Ana log display of vehicle
speed in MPH or km/h.
2. In
formation Display Area - Odometer / Trip Meter
/ Tac hometer / Engine Temperature / Engine
Hours / Service Info / Cl ock - LCD displa y of the
service hour interval, total vehicle miles or km., total
engine hours, a trip meter, engine RPM a nd engine
temperature.
3. MPH / KM/H Display
- MPH is dis played when the
instrument cluster is in the Standard mode. KM/H is
displayed when the instrument cluster is in the Metric
mode.
4. High Beam Ind
icator LED icon illuminates whenever
the Headlamp switch is in the high beam position.
5. Fu
el L evel Indicator - LCD b ar g raph indicating
current fuel level. All segments will flash when the last
segment is cleared indicating a low fuel warning.
6. Clock
- Displays current time in either 12-hour or 24-
hour formats.
7. Engine
T emperature Indicator - L ED icon
illuminates when the ECM de termines the engine is
overheating. The indicators will initially flash to
indicate the engine is overheating. The indicators will
stay lit and not flash if a severe overheating condition
exists.
8. Ser
vice Interval Indicator - Preset at the factory and
adjustable by the user , a flashing wre nch sym bol
alerts the operator that the preset service interval has
been reached and maintenance should be performed.
The wrench icon will flash for 10 seconds upon start-
up once it reaches 0.
9. Chec
k Engine MIL - Illuminated when the ECM has
detected a Diagnostic Trouble Co de in th e eng ine
management system.
10. AWD
Indicator - Illuminated when the AWD / TURF
switch is in the AWD position.
11. TURF Indica
tor - Illuminated when the AWD / TURF
switch is in the TURF position (INTL Models Only).
12. Ne
utral Gear Indicator - LED icon illuminates when
gear selector is in the neutral (N) position.
13. Gea
r Posit ion In dicator - Displays gear selec tor
position.
H = High
L = Low
N = Neutral
R = Reverse
P = Park
-- = Gear Signal Error (shifter stuck between gears)
14. Po
wer Steering System MIL - LED icon illuminates
when a fault ha s occu rred with the powe r steering
system. This indicator illuminates when the key is
turned to the ON po sition and goe s o ff when the
engine is started.
15. T
urn Signal / Hazar d La mp Indica tor - LED icon
illuminates whenever the LH, RH or hazard lamps are
activated (INTL Models Only).
16. Hel
met / Seat Belt Indicator - LED icon illuminates
for several seconds when the key is turned to the ON
position. T he la mp is a r eminder to the op erator to
ensure all riders are wearing helmets and seat belts
before operating the vehicle.
Information Display Area
The LC D p ortion of the in strument c luster is the
information display a rea. In formation dis played in this
area includes: odometer, trip meter, engine RPM, engine
hours, service interval, clock, engine Diagnostic Trouble
Codes (DTCs) and power steering DTCs.
Odometer
The o dometer reco rds an d disp lays the to tal dist ance
tr
aveled by the vehicle. The odometer can not be reset.
