2.11
MAINTENANCE
2
9923523 - RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
4. Adjust the shift cable so there is the same amount of
cable travel when shifting slightly past the detents of
HIGH (H) gear and PARK (P).
5. Thread jam nut (A) or (B) as required to obtain proper
ca
ble adjustment.
NOTE: This procedure may require a few attempts to
ob
tain the proper adjustment.
6. Once the p roper ad justment is obtained, place the
shift
cable and jam nut (B) into the mount. Tighten jam
nut (A) against the mount.
7. Start engine and shift through all gears to ensure the
shift
cable is properly adjusted. If transmission still
ratchets after cable adjustment, the transmission will
require service.
FUEL SYSTEM AND AIR INTAKE
Fuel System
Fuel Line
1. Check the quick-connect fu el line from th e en gine
fuel rail conn ection to th e fu el ta nk connection for
signs of wear, de terioration, da mage or leakag e.
Replace if necessary.
2. Be sure fuel line is routed and retained properly.
IMPORTANT: Make sure line is not kinked or pinched.
3. Replace fuel line every two years.
Gasoline is extremely flammable and explosive
under certain conditions.
Always stop the engine and refuel outdoors or in
a well ventilated area.
Do not smoke or allow open flames or sparks in
o
r near the area where refueling is performed or
where gasoline is stored.
Do not overfill the tank. Do not fill the tank
neck.
If you get gasoline in your eyes or if you swallow
ga
soline, seek medical attention immediately.
If you spill gasoline on y
our skin or clothing,
immediately wash it off with soap and water
and change clothing.
Never start the engine or let it run in an enclosed
ar
ea. Engine exhaust fumes are poisonous and
can result in loss of consciousness or
death in a short time.
Never drain the fuel when the engine is hot.
Severe burns
may result.
