3.31
ENGINE / COOLING SYSTEM
3
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Engine Installation
Use the following pr ocedure to re install th e eng ine
assembly.
1. Attach en gine with suit a
ble lift ing str aps t o a n
overhead or portable engine hoist.
2. Remove the engine stand adapter plate.
3. Use the ove rhead or p ortable engine ho ist a nd
suitab
le e ngine straps to lower the en gine in to the
vehicle frame.
NOTE: Have an a ssistant help gu ide the eng ine in
a
nd out of the vehicle while using an engine hoist to
prevent pe rsonal injur y or dama ge to vehicle
components.
4. By hand, install the (4) front engine mount bolts and
nuts
(A). Do not tighten at this time.
5. Instal the (4) engine to tran
smission coupler plates (B)
and instal the ( 8) bo lts and washe rs ( C). Do no t
tighten fasteners at this time.
IMPORTANT: DO NOT torque f
asteners at this time.
6. Install the Clutch Ce nter Distance To
ol (PU-5 0658)
onto th e cr ankshaft and tr ansmission in put shaft t o
properly position the clutch center distance. ï€
ï€
The pictures below show the to
ol (PU-50658) properly
installed.
Drive Clutch Bolt Installed
PU-50658
To Next Page
