3.30
ENGINE / COOLING SYSTEM
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
25. Remove the (3) hex bolts (K) securing the exha ust
head pipe to the eng ine. Remo ve th e (3 ) r ubber
exhaust hangers (L) securing the exhaust system to
the main frame. Discard the exhaust seal and replace
with new for reassembly.
26. Maneuver the exhaust system towards the right-hand
side
of the vehicle to gain engine removal clearance.
Removal of the exhaust system from the chassis is not
needed.
27. Place a s upport in -between th e main fra me and
tra
nsmission case. Do not pinch brake line.
28. Use an overhead or portable engine hoist and suitable
en
gine s traps t o s ecure the engine in its cu rrent
position.
29. Remove the (4) bolts and nuts (M) securing the engine
to the front
motor mount bracket.
30. Remove the ( 8) b olts (N) securing th e cou pler
bra
ckets to the engine and transmission.
31. Loosen the (2) bolts and nuts (O) so the engine mount
bra
cket can be slightly tilted away from engine.
32. With the h elp of an assista nt an d the en gine ho ist,
raise
the engine vertically out of the vehicle frame.
NOTE: Have a n ass istant help guide t he e ngine in
and out
of the vehicle while using an engine hoist to
prevent per sonal injury or dama ge t o th e ve hicle
components.
33. Install the engine stand adapter (PU-50824) onto the
eng
ine PTO side mounting ears as shown below.
34. Select th e pr oper eng ine stan d slee ve ada pter an d
insta
ll it onto the engine stand adapter.
• Sleeve adapter for a 2” bore engine stand: 
(PU-50625)
• Sleeve adapter for a 2.375” bore engine stand: 
(PW-47054)
35. Place engine onto the engine stand (PU- 50624) for
se
rvice.
L
K
L
Discard
N
O
M
PU- 50824
Bolts From The
Center Outward
