CLUTCHING
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Overheating / Diagnosis
During routine maintenance, or whenever PVT system overheating is evident, it’s important to check the inlet and outlet
ducting for obstructions. Obstructions to air flow th rough the ducts will significantly increase PVT system operating
temperatures. The vehicle should be operated in Low when plowing or pulling heavy load s, or if extended low s peed
operation is anticipated.
Operating in Low Gear
Low gear s hould be used when pulling heavy loads, riding through rough terrai n, or when basic operational ground
speeds are less than 7 MPH. Use High gear when basic operational ground speeds are more than 7 MPH.
IMPORTANT: Using High gear for heavy loads, hilly terrain, or
in wet, muddy conditions will increase the chance
of drive belt burning.
CLUTCH DRIVE BELT & COVER RELATED ISSUES: DIAGNOSIS
Possible Causes Solutions / What to do
Loading the vehicle into a truck or tall
trailer when in high range.
Shift transmission to Low during loading of th
e vehicle to prevent belt burning.
Starting out going up a steep incline from
a sto
pped position.
When starting out on an incline, use Low gear. Shift transmission to Low
during loading of the vehicle to prevent belt burning.
Driving at low RPM or
low ground speed
(at approximately 3-7 MPH).
Drive at higher speed or use Low. The use of Low is highly recommended for
cooler PVT operating temperatures and longer component life.
Insufficient engine warm-up when
expo
sed to low ambient temperatures.
Warm engine at least 5 min., then with tra
nsmission in neutral, advance
throttle to approx. 1/8 throttle in short bursts, 5 to 7 times. The belt will
become more flexible and prevent belt burning.
Slow and easy clutch engagement. Fast, effective use of the throttle for efficient engagement.
Towing/Pushing at low RPM or low
gr
ound speed.
Use Low only.
Plowing snow, dirt, etc./utility use. Use Low only.
Stuck in mud or snow.
Shift the transmission to Low, carefully us
e fast, aggressive throttle
application to engage clutch. WARNING: Excessive throttle may cause loss
of control and vehicle overturn.
Climbing over large objects from a
sto
pped position.
Shift the transmission to Low, carefully us
e fast, aggressive, brief throttle
application to engage clutch. WARNING: Excessive throttle may cause loss
of control and vehicle overturn.
Belt slippage from water or snow
ingest
ion into the PVT system.
Shift the transmission to n
eutral. Using the throttle, vary the engine rpm from
idle to full throttle. Repeat several times as required. During this procedure,
the throttle should not be held at the full position for more than 10 seconds.
Clutch seals should be inspected for damage if repeated leaking occurs.
Clutch malfunction.
Clutch component inspection should be performed by a Polaris MSD certified
technician.
Poor engine performance.
Fouled spark plugs, foreign material in fuel t
ank, restricted fuel lines, or faulty
fuel pump may cause symptoms similar to clutching malfunction.
GENERAL RANGE OPERATION
GUIDELINES:
Low: Heavy pulling, basic operational speeds less than 7 MPH, riding
thr
ough rough terrain (swamps, mountains, ect.), or low ground speeds.
High: High ground speeds, or speeds above 7 MPH.
