1.2
GENERAL INFORMATION
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
MODEL INFORMATION
Model Identification
The machine model number must be used with any correspondence regarding warranty or service.
Engine Designation Number
1204286..............................................................................Single Cylinder, Liquid Cooled, OHV 4 Stroke, Electric Start
VIN Identification
Vehicle and Engine Serial Number Lo
cation
Whenever corresponding about a Polaris ORV, refer to the ve hicle identification number (VIN) and the engine serial
number.
The VIN can be found stamped on a portion of the left-han
d rear upper frame rail, above the left rear wheel. 
(see Figure 1-1)
The engine model and serial number can be found on a decal applied to the crankcase on the front of the engine. 
(see Figure 1-2)
}
Machine Model Number Identification
}
}
Model Year
Designation
Basic Chassis 
Designation
Engine Designation
Emissions & 
Model Option
R 1 2 V H 5 7 A D
}
4 X A V H 5 7 A * B P 0 0 0 0 0 0
}
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
World
Mfg. ID
Engine
Vehicle Description
Vehicle Identifier
Check Digit
Model
Year
Body Style
Plant No.
Individual Serial No.
* This could be either
a number or a letter
Powertrain
Emissions
Figure 1-1
Engine Serial
Figure 1-2
Number
