9.24
BRAKES
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
4. Slowly pump the brake pedal until pressure has been
built up. Maintain at least 1/2, (12.7 mm) of brake fluid
in the reservoir to prevent air from entering the brake
system.
5. Install th e a djustment se t
screw and turn clockw ise
until the stationary pad contacts the disc, then back
off 1/2 turn.
6. Verify fluid level in rese r
voir is up to t he M AX lin e
inside reservoir and install reservoir cap.
7. Install wheel and torque wheel nuts to specification.
Brake Burnishing Procedure
It is r equired that a burnishing procedure be performed
after installation of new brake pads to extend service life
and reduce noise.
Start machin e an d slo wly in crease speed to 30 mp h.
Gra
dually apply brakes to stop machine. Allow pads and
disc to coo l suf ficiently d uring the pr ocedure. Do n ot
allow pads or disc to become hot or warping may result.
Repeat this pr ocedure 1 0 times. Do not make more
than 3 stops per 1 mile (1.6 km).
Master Cylinder Fluid
Up to MAX line inside reservoir
Wheel Nuts:
Steel Wheels: 27 ft. lbs. (37 Nm)
Aluminum Wheels: 30 ft. lbs. + 90° (1/4 turn)
