Polaris 2012 RANGER RZR 570 INTL User Manual

5.26
BODY / STEERING / SUSPENSION
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
REAR STABILIZER BAR
Removal / Installation
1. Remove the cargo box access panel.
2. Remove the bushing retaining nut (A) from the upper
portion of the stabilizer bar linkage on each side of the
ve
hicle.
3. Remove the (4) fasteners (B) retaining the s
tabilizer
bar bracket to the frame. Remove the bushing and
bushing brackets from the vehicle.
4. Remove the stabilizer bar
from the vehicle.
NOTE: Rotate th e st abilize b ar 18 0 de grees s o th e
linkage hole (C
) is facing rearward to aid in stabilizer
bar removal.
5. Inspect the stabilizer bar for straightnes
s. Inspect the
bushings and replace if needed.
6. Inspect the r ubber bushings on the linkage rod and
r
eplace if needed.
7. Reverse the procedure for installation.
8. Torque the stabilizer mo unting
nuts (B) to
specification.
9. Torque th e bu shing re taining nu t ( A) o n the upp er
portion of
the stabilizer bar linkage to specification.
= T
Stabilizer Mounting Bolt Torque:
18 ft. lbs. (24 Nm)
= T
Stabilizer Bushing Retaining Nut Torque:
30 ft. lbs. (40.5 Nm)
A
B
C
Bracket
Linkage
Bushing
18 ft. lbs.
(24 Nm)
37 ft. lbs.
(50 Nm)
30 ft. lbs.
(40.5 Nm)
