Polaris 2012 RANGER RZR 570 INTL - Chassis; Main Frame

5.11
BODY / STEERING / SUSPENSION
5
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Chassis / Main Frame
Main Frame
Bolt-In Brace
Skid Plate
Rear Bumper
Support
6-8 ft. lbs.
(8-11 Nm)
Washer
Plug
17 ft. lbs.
(23 Nm)
Front Cross Member
Bolt-In Brace
Rear Cross Member
17 ft. lbs.
(23 Nm)
Shield
40 ft. lbs.
(54 Nm)
