SHIFT CABLE
Inspection
Shift cable adjustment may be nec essary if symptoms
include:
• No gear position or AWD display on instrument
cl
uster
• Ratcheting noise on deceleration
• Inability to engage into a gear
• Excessive gear clash (noise)
• Gear selector moving out of desired range
Inspect shif t cab le, clevis pin s, a nd pivot bu shings a nd
r
eplace if worn or damaged.
Adjustment
1. Locate th e s hift ca ble a ttached to the transmission
case in the right rear wheel well area.
2. Inspect shift cable, clevis pin, p
ivot bushings, and dust
boot. Replace if worn or damaged.
3. If adjustment is required, loosen the lower jam nut and
pull the cab
le out of the mount to move the upper jam
nut.
4. Adjust the shift cable so there is the same amount of
ca
ble travel when shifting slightly past HIGH gear and
PARK.
5. Thread th e up per or lower jam nu t a s r equired to
o
btain proper cable adjustment.
NOTE: This procedure may require a few attempts to
obt
ain the proper adjustment.
6. Once th e pr oper adju stment is obtained, place th e
sh
ift cable and upper jam nut into the mount. Tighten
the lower jam nut against the mount.
7. Start engine and shift through all gears to ensure the
s
hift c able is properly adjusted. If trans mission s till
ratchets after cable adjustment, the transmission will
require service.
Pin and
Shift Cable
Mount
Bushings
Dust Boot
