ELECTRONIC FUEL INJECTION
4
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
6. Throttle Body
- Located between the rubber air box boot and rubber
cylinde
r he ad ad aptor un der th e ca rgo bo x access
panel.
7. Th
rottle Position Sensor (TPS)
- Located on the right-hand side of the throttle body
below the IA
C motor.
8. Idle Ai
r Control Motor (IAC)
- Located on the upper right-hand side of the throttle
b
ody above the TPS.
9. En
gine Coolant Temperature Sensor (ECT)
- Lo cated in the cylinder h ead und erneath the
th
ermostat housing. The sensor can be accessed with
the rear service p anel, cargo box access panel and
the clutch outlet hose removed.
10. Ign
ition Coil
- Located in the LH rear wheel well area, behind the
PVT inlet
hose.
Throttle Body
TPS
IAC
ECT
Ignition Coil
PVT Inlet Hose
