4.36
ELECTRONIC FUEL INJECTION
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
ECU Output Supply Voltage 1
Voltage Too High
3597
3 P16A2
Voltage Too Low 4 P16A1
ECU Output Supply Voltage 2
Voltage Too High
3598
3 P16A9
Voltage Too Low 4 P16A8
All Wheel Drive Control Circuit
(A
WD)
Driver Circuit Open / Grounded
520207
5 P1836
Driver Circuit Short to B+ 3 P1835
Driver Circuit Grounded 4 P1834
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 1
Driver Circuit Open / Grounded
520271
5 P1505
Driver Circuit Short to B+ 3 P1509
Driver Circuit Grounded 4 P1508
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 3
Driver Circuit Open / Grounded
520268
5 P1515
Driver Circuit Short to B+ 3 P1519
Driver Circuit Grounded 4 P1518
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 4
Driver Circuit Open / Grounded
520269
5 P1525
Driver Circuit Short to B+ 3 P1529
Driver Circuit Grounded 4 P1528
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 6
Driver Circuit Open / Grounded
520270
5 P1535
Driver Circuit Short to B+ 3 P1539
Driver Circuit Grounded 4 P1538
DIAGNOSTIC TROUBLE CODE TABLE
Component Condition SPN FMI
Digital Wrench™
P-Code
