4. Remove the (2) upper radiator retaining bolts (A) and
remove the (4) bolts (B) retaining the lo wer radiator
mount bracket and remove the bracket from the frame
5. Allow radiator to sag down to allow access to recovery
bottle retaining screws an d filler neck
retaining
screws.
6. Remove re taining scr ews fro m recovery bo ttle an d
filler neck. Allow the recovery
bottle and filler neck to
hang down to access the (4) bolts retaining the upper
radiator mount bracket.
7. Remove th e ( 4) bo lts re taining t he up per ra diator
m
ount br acket an d r emove the br acket fr om th e
frame.
8. Lift up on the stabilizer bar
and remov e it from the
vehicle.
9. Inspect the stabilizer bar for
straightness. Inspect the
bushings and replace if needed.
10. Reverse the pro cedure for installatio n. Torque th e
linkage
fasten ers to spe cification ( see “Exploded
View”).
