6.6
CLUTCHING
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
6. Remove the (8) clutch cover screws and remove the
outer clutch cover from the vehicle.
7. Mark the drive belt direction of rotation and remove
drive belt (s
ee “DRIVE BELT - Belt Removal”).
8. Remove the d riven clutch r etaining b olt and dri ven
clutch.
9. Install the Drive Clutch Holder PN 9314177.
10. Remove the dr ive clutch r etaining b olt an d r emove
dr
ive clutch using the Drive Clutch Puller PA-48595.
IMPORTANT: Be sure to use th
e correct Drive Clutch
Puller (PA- 48595) to prevent damage to crankshaft.
11. Loosen hose clamp attaching the PVT inlet duct to the
in
ner c lutch co ver. D isengage ho se fr om t he in ner
clutch cover.
12. Loosen the hose clamp (A) that atta
ch the clutch outlet
duct to th e inn er clutch cover . Disengage th e hose
from the cover.
13. Remove the (8) bolts that retain the inner clutch cover
to th
e engine and transmission. Remove inner clutch
cover. Make note of ca ble and hose routings for
assembly.
Drive Clutch Puller PA-48595
Drive Clutch Holder 9314177
