7.39
FINAL DRIVE
7
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
7. Install NEW brake caliper mounting bolts and torque
to 44 ft. lbs. (60 Nm).
8. Torque wheel hub nut to 80 ft. lbs. (1 08 Nm) and
install a N EW c otter p in. T ighten nut slightly if
necessary to align cotter pin holes.
9. Install wheel and (4) wheel nuts. Torque wheel nuts
to spec
ification.
= T
Rear Caliper Mounting Bolts:
44 ft. lbs. (60 Nm)
CAUTION
New bolts have a pre-applied locking agent
which is destroyed upon removal. Always use
new brake caliper mounting bolts
upon assembly.
44 ft. lbs.
60 (Nm)
= T
Wheel Hub Castle Nut:
80 ft. lbs. (108 Nm)
= T
Wheel Nuts:
Steel Wheels: 27 ft. lbs. (37 Nm)
Aluminum Wheels: 30 ft. lbs. + 90° (1/4 turn)
80 ft. lbs.
(108 Nm)
NEW Cotter Pin
