8.45
TRANSMISSION
8
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Exploded View, Continued
Ref. Qty. Description Ref. Qty. Description
1. 1 Fill Plug 46. 1 Gear, Sector 16T
2. 1 Drain Plug, Magnetic 47. 1 Gear, Sector 31T
3. 14 Screw, M8 x 1.25 x 30 48. 1 Pawl, Detent
4. 6 Screw, M6 x 1 x 20 49. 1 Star, Detent
5. 3 Screw, M8 x 50 50. 1 Plate, Park, 12-Face
6. 1 Screw, M6 x 1 x 40 51. 1 Shaft, Output 53T
7. 6 Screw, M6 x 1 x 18 52. 1 Shaft, Idler 29T
8. 1 Nut, NyLoc, M8 x 1.25 53. 1 Shaft, Front Output
9. 2 Washer, Cup 54. 1 Shaft, Input, Helical
10. 3 Washer 55. 1 Shaft, Reverse, 27T
11. 1 Washer 56. 1 Bellcrank
12. 1 Washer 57. 1 Collar, Shift
13. 2 Pin, Dowel 58. 1 Rail, Shift Shaft
14. 1 Pin, Spring 59. 1 Tube, Vent, 1/4 in.
15. 1 Retaining Ring, External 60. 1 Shift Dog, Park
16. 1 Snap Ring 61. 1 Gear, 44T
17. 1 Retaining Ring, External 62. 2 Fork, Shift
18. 1 Retaining Ring, External 63. 1 Sprocket, 48T, 6-Face
19. 1 Retaining Ring, Internal 64. 1 Gear, Low 67T
20. 2 Retaining Ring, External 65. 1 Engagement Dog, 6-Face
21. 2 Retaining Ring, External 66. 1 Gear, 53T
22.
3 Retaining Ring, External 67. 1 Shaft, Pinion 11T
23. 1 Retaining Ring, External 68. 1 Gear, 46T
24. 2 Washer, Thrust 69. 1 Gear, Snorkel 13T
25. 1 Washer, Thrust 70. 1 Shaft, Shift
26. 1 Shim 71. 1 Weldment, Rear Mount Bracket
27. 1 Shim 72. 1 Bracket, Rear Mount
28. 2 Bearing, Needle Cage 73. 1 Cover, Bearing, Center Drive
29. 2 Bearing, Ball 74. 1 Spacer
30. 2 Bearing, Ball 75. 1 Chain, Silent
31. 2 Bearing, Ball 76. 1 Switch, Rotary, 2-Pin
32. 3 Bearing, Ball 77. 1 O-Ring
33. 1 Bearing, Needle Cage 78. 1 O-Ring
34. 1 Bearing, Ball 79. 1 O-Ring
35. 2 Bearing, Ball 80. 1 Seal, Triple Lip
36. 1 Wire Harness Bracket 81. 1 Seal, Dual Lip
37. 2 Spring, Compression 82. 1 Seal, Triple Lip
38. 2 Spring, Compression 84. 1 Sensor, Speed
39. 1 Spring, Compression, Detent
40. 1 Washer, Spring
41. 1 Tube, Snorkel
42. 1 Cover, Sector Gears
43. 1 Case, LH
44. 1 Case, LH
45. 1 Drum, Shift
