TRANSMISSION
8
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
Exploded View, Continued
Ref. Qty. Description Ref. Qty. Description
1. 1 Fill Plug 53. 1 Pawl, Detent
2. 1 Drain Plug, Magnetic 54. 1 Star, Detent
4. 14 Screw, M8 x 1.25 x 30 55. 1 Plate, Park, 12-Face
5. 6 Screw, M6 x 1 x 20 56. 1 Shaft, Idler 29T
6. 3 Screw, M8 x 50 57. 1 Shaft, Reverse 29T
7. 1 Screw, M6 x 1 x 40 58. 1 Shaft, Front Output
8. 6 Screw, M6 x 1 x 18 59. 1 Shaft, Input Helical
9. 2 Screw, M6 x 1 x 16 60. 1 Shaft, Pinion, 11T
10. 1 Nut, NyLoc, M8 x 1.25 61. 1 Disc, Brake
11. 2 Washer, Cup 62. 1 Bellcrank
12. 1 Washer 63. 1 Collar, Shift
13. 3 Washer 64. 1 Rail, Shift Shaft
14. 1 Washer 65. 1 Tube, Vent, 1/4 in.
15. 1 Washer 66. 1 Fork, Pivot Shaft
16. 2 Pin, Dowel 67. 1 Dog, Engagement
17. 1 Pin, Spring 68. 1 Shift Dog, Park
18. 1 Retaining Ring, External 69. 1 Gear, 44T
19. 1 Snap Ring 70. 2 Fork, Shift
20. 1 Retaining Ring, External 71. 1 Sprocket, 48T, 6-Face
21. 1 Retaining Ring, External 72. 1 Gear, Low 67T
22. 1 Retaining Ring, Internal 73. 1 Engagement Dog, 6-Face
23.
2 Retaining Ring, External 74. 1 Gear, 53T
24. 2 Retaining Ring, External 75. 1 Gear, 46T
25. 3 Retaining Ring, External 76. 1 Gear, Snorkel 13T
26. 1 Retaining Ring, External 77. 1 Shaft, Shift
27. 2 Washer, Thrust 78. 1 Weldment, Rear Mount Bracket
28. 1 Washer, Thrust 80. 2 Retainer, Fork
29. 1 Shim 81. 1 Bracket, Rear Mount
30. 1 Shim 82. 1 Cover, Bearing, Center Drive
31. 2 Bearing, Needle Cage 83. 1 Spacer
32. 2 Bearing, Ball 84. 1 Chain, Silent
33. 1 Bearing, Ball 85. 1 Solenoid
34. 2 Bearing, Ball 86. 1 Switch, Rotary, 2-Pin
35. 3 Bearing, Ball 87. 1 O-Ring
36. 1 Bearing, Needle Cage 88. 1 O-Ring
37. 1 Bearing, Ball 89. 1 O-Ring
38. 2 Bearing, Ball 90. 1 Seal, Triple Lip
39. 1 Bearing, Ball 91. 1 Seal, Triple Lip
40. 2 Spring, Compression 92. 1 Seal, Dual Lip
41. 2 Spring, Compression 93. 2 Seal, Triple Lip
42. 1 Spring, Torsion 95. 1 Sensor, Speed
43. 1 Spring, Compression 98. 1 Bracket, Wire Harness
44. 1 Spring, Compression, Detent 99. 2 Plug, Expansion
45. 1 Spring, Washer
100. 1 Side Gear, Male, 39T
46. 1 Tube, Snorkel 101. 3 Bearing, Plain
47. 1 Cover, Sector Gears 102. 1 Side Gear, Female, 39T
48. 1 Case, LH 103. 1 Diff Cover
49. 1 Case, RH 104. 6 Planet Gear
50. 1 Drum, Shift 105. 7 Screw, M8 x 1.25 x 25
51. 1 Gear, Sector 16T 106. 1 Ring Gear, 53T
52. 1 Gear, Sector 31T 108. 6 Bearing, Plain
