9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
MODEL: 2012 RANGER RZR 570
MODEL NUMBER: R12VH57AD
ENGINE NUMBER: 1204286
CLUTCH CHART
Engine
Platform
Domestic Single Cylinder, Liquid
Co
oled, 4-Stroke, DOHC
Engine Number 1204286
Engine Displacement 567cc
Number of Cylinders 1
Bore & Stroke (mm) 99 x 73.6 mm
Compression Ratio 10:1
Compression Pressure 80 - 120 psi (decompression)
Engine Idle Speed 1200 ± 100 RPM
Engine Max Operating RPM 7750 RPM
Lubrication Pressurized Wet Sump
Oil Requirements PS-4 Plus Synthetic
Oil Capacity 2 qts. / 1.9 liters
Coolant Capacity 4.25 qts. (4 l)
Overheat Warning Instrument Cluster Indicator
Exhaust System
Single Headpipe / Single Silencer
Fuel System
Fuel System Type Bosch M17 EFI
Fuel Delivery Electronic Fuel Pump (in tank)
Fuel Pressure 43-48 psi (296.5 - 331 KPA)
Fuel Filters In tank, See Chapter 4
Fuel Capacity / Requirement
7.25 gal. (27.4 liters)
87 Octane (minimum)
Electrical
Alternator Max Output 650 Watts @ 7000 RPM
Headlights 2 - Halogen: Single Beam 55W
Tail / Brake 2 - 6 Watts / 2 - 27 Watts
Starting System Electric Start
Ignition System Bosch M17 (ECU Controlled)
Ignition Timing (Variable) ECU Controlled
Spark plug / Gap
RG4YCX / .0276” - .0315”
(
.7 - .8 mm)
Battery (RZR)
Yuasa YB14-B2 /
14 Amp
Hr. / 12 Volt
Instrument Type Multifunction Instrument Cluster
DC Outlet Standard 12 Volt
Relays
EFI / Chassis / Fan / Fuel Pump /
Hea
dlight
Circuit Breaker Fan Motor: 20 Amp
Fuses (Fuse/Relay Box)
Drive / Fuel Pump: 10 Amp
Li
ghts / EFI / Accessory: 20 Amp
Fuses (Power Fuse Holder)
EFI: 30 Amp
Chas
sis: 30 Amp
Drivetrain
Transmission Type Polaris Automatic PVT
Drive Ratio - Front 3.818:1
Drive Ratio - Final 3.70:1
Shift Type In Line Shift - H / L / N / R / P
Front Gearcase
Fluid Type / Capacity
Polaris Demand Drive Plus
6.75 oz. (200 ml)
Transmission: Main Gearcase
Fluid Type / Capacity
Polaris AGL Plus
44 oz. (1300 ml)
Belt 3211143
Steering / Suspension
Front Suspension
Independent Dual A-arm
w/Anti-Sway Bar
Front Travel 9 in. / 23 cm
Rear Suspension
Independent Dual A-arm
w/Anti-Sway Bar
Rear Travel 9.5 in. / 24 cm
Shock Preload Adjustment
Front / Rear
Cam Adjustment
Cam Adjustment
Toe Out
1/8 - 1/4 in. (3 - 6.4 mm)
Wheels / Brakes
Front Wheel Size
Front Tire Type / Size
12 x 6 / Steel
Ancla / 25 x 8 R12
Rear Wheel Size
Rear Tire Type / Size
12 x 8 / Steel
Ancla / 25 x 10 R12
Tire Pressure
Front: 10 psi (69 kPa)
Rear: 12 psi (83 kPa)
Brake - Front / Rear
Foot Actuated - 4 Wheel
Hydraulic Disc
Brake Fluid DOT 4
Altitude
Shift
We
ight
Drive
Spring
Meters
(Feet
)
0-1500
(0-5000)
25-52
(5
632409)
Black
(7043594)
1500-3700
(50
00 - 12000)
25-48
(5632408)
Black
(7043594)
