Chapter 14 PI-MAX4: EM Family 223
Once an EM Gain value in excess of 100 has been entered, an Experiment Warning
is raised by LightField. See Figure 14-8.
Figure 14-8: Typical EM Gain Configuration Display for EM Gain > 100
NOTE:
When switching operation between Optimal and Manual
modes, any configuration settings or adjustments made within
Manual mode will be retained.
4411-0139_0124
