Princeton Instruments PI-MAX4 - Figure B-10: Outline Drawing: PI-MAX4: 1024 I-RF with Spectroscopy-Mount; Adapter

284 PI-MAX
®
4 System Manual Issue 9
Figure B-10: Outline Drawing: PI-MAX4: 1024i-RF with Spectroscopy-mount Adapter
225.0
REMOVEABLE EXTENDER BRACKET
M6x1.0
0.25
0.25
1/4-20 THREAD
6.5mm
1/4-20 THREAD
9.00
50.8
0.52
3.26
1.000 25.40
1.969
71.1
50.00
2.00
0.20
0.25[6.4]
5.1
2X
0.129
2.80
18.3mm
SEE NOTE 2.
CATHODE COOLING INPUT
3.88 BOLT CIRCLE
ON
3X #10-32 THREAD
3X 0.20[5.2] RADIAL SLOT ON
3.60 BOLT CIRCLE
SEE NOTE 2.
170.76.72
114.34.50
1.94 49.3
SEE NOTE 1.
AIR INTAKE VENTS
MOUNTING FACE
AIR EXHAUST VENTS
1.50.06
66.042.600
8.85±0.03
224.7±0.8
1.26
32.0
0.15
3.8
23.57 15.21
INTENSIFIER DEPENDANT
0.928 0.599
4.250 107.95
AIR INTAKE VENTS
INCREMENTS.
NOTES: 1. MOUNTING FACE TO IMAGE PLANE IS FACTORY PRESET
TO OPTICAL DISTANCE OF 0.894
0.010 [22.71 0.25].
2. MOUNTING FLANGE ORIENTATION CAN BE ROTATED IN 180
4411-0139_0157
