278 PI-MAX
®
4 System Manual Issue 9
B.2 PI-MAX4: 512 EM/512 EM(B)
Figure B-4: Outline Drawing: PI-MAX4: 512 EM/512 EM(B) with C-mount Adapter
REMOVABLE EXTENDER BRACKET
0.25]
NOTES:
1. MOUNTING FACE TO IMAGE PLANE IS FACTORY PRESET
TO OPTICAL DISTANCE OF 0.690
± 0
.010 [17.53 ±
AIR EXHAUST
AIR INTAKE
MOUNTING FACE
SEE NOTE 1.
88.
93.50
233.6
74.72.94
±0.03 ±0.89.20
INTENSIFIER DEPENDANT
38.3
26.3
1.51
1.04
1.10 27.9
1/4-20 THREAD
2X 0.129 [3.3 ] HOLES
M6x1.0 THREAD
1/4-20 THREAD
225.0
2.00
mm
0.71
25.41.00
50.0
9.00
mm
0.20 5.1
23.1mm
AIR INTAKE
SEE NOTE 1.
1.00"-32 THREAD
CATHODE COOLING INPUT
114.34.50
114.34.50
1.94 49.3
2. DIMENSIONS IN INCHES [mm]
3. TOLERANCES: ± 0.01 [±0.25]
4. WEIGHT: CAMERA
6.86 lbs (3.12 kg)
POWER SUPPLY
4.1 lbs (1.87 kg)
4411-0139_0151
