5.14.4 SuperSYNCHRO Timing Expander
The Super SYNCHRO Timing expander is located at the bottom of the LightField desktop.
See Figure 5-28.
NOTE:
The top of the SuperSYNCHRO Timing expander can be:
• Dragged up to view more of the
SuperSYNCHRO
panel;
• Dragged down to view more of the
Experiment
Settings stack or the Device/View panel.
Figure 5-28: SuperSYNCHRO Timing Expander
