Chapter 5 Gate Mode Operation 91
From this expander, the following parameters are configured:
• Frames to Save
Configures how many images will be acquired.
• On-CCD Accumulations
Configures whether multiple frames will be used to create a single frame.
• Exposures per Frame
Configures whether multiple exposures will occur while a frame is being acquired.
• Intensifier
— Enable Intensifier
When checked, the Intensifier is enabled.
— Intensifier Gain
Configures the level of Intensifier Gain.
• Advanced Intensifier
Figure 5-24 illustrates a typical Advanced Intensifier dialog.
Figure 5-24: Typical Advanced Intensifier Dialog
The following advanced parameters are configured on this dialog:
— Phosphor Decay Delay
— Phosphor Decay Resolution
• Time Stamping
Configures which, if any, of the following time stamp information is to be stored
and displayed with the data:
— Exposure Started;
— Exposure Ended.
• Frame Tracking
