Appendix B Outline Drawings 277
Figure B-3: Outline Drawing: PI-MAX4: 1024i/1024f/2048f/1024x256 with Spectroscopy-mount Adapter
225.0
SEE NOTE 1.
AIR INTAKE VENTS
MOUNTING FACE
AIR EXHAUST VENTS
3.8
0.15
INTENSIFIER DEPENDANT
15.21
23.57
1.50.06
66.042.600
8.85±0.03 224.7±0.8 1.26 32.0
0.928 0.599
4.250 107.95
AIR INTAKE VENTS
1/4-20 THREAD
0.25
0.52
50.8
9.00
1.000
2.00
71.1
3.26
1.969
25.40
5.1
0.25[6.4]
0.20
50.00
2X
0.129
2.80
18.3mm
1/4-20 THREAD
6.5mm
0.25
M6x1.0
REMOVEABLE EXTENDER BRACKET
ON SEE NOTE 2.
3.88 BOLT CIRCLE
CATHODE COOLING INPUT
3X #10-32 THREAD
3X 0.20[5.2] RADIAL SLOT ON 3.60 BOLT CIRCLE
SEE NOTE 2.
4.50 114.3
4.50 114.3
1.94 49.3
INCREMENTS.
NOTES: 1. MOUNTING FACE TO IMAGE PLANE IS FACTORY PRESET
TO OPTICAL DISTANCE OF 0.894
0.010 [22.71 0.25].
2. MOUNTING FLANGE ORIENTATION CAN BE ROTATED IN 180
4411-0139_0150
