Princeton Instruments PI-MAX4 - Figure B-2: Outline Drawing: PI-MAX4: 1024 I;1024 F;2048 F;1024 X256 with

276 PI-MAX
®
4 System Manual Issue 9
Figure B-2: Outline Drawing: PI-MAX4: 1024i/1024f/2048f/1024x256 with F-mount Adapter
REMOVABLE EXTENDER BRACKET
INCREMENTS.
NOTES: 1. MOUNTING FACE TO IMAGE PLANE IS FACTORY PRESET TO OPTICAL DISTANCE OF 1.831
0.010 [46.50 0.25].
2. LENS RELEASE TRIGGER ORIENTATION CAN BE
ROTATED IN 180
CATHODE COOLING INPUT
NIKON "F" MOUNT ADAPTER SEE NOTES 1 AND 2.
114.34.50
114.3
4.50
1.94 49.3
AIR INTAKE VENTS
SEE NOTE 1.
MOUNTING FACE
AIR EXHAUST VENTS
224.7±0.88.85±0.03
88.93.50
32.01.26
2.30 58.4
1.865 1.536
47.38 39.02
INTENSIFIER DEPENDANT
AIR INTAKE VENTS
0.25
M6x1.0
0.25
1/4-20 THREAD
6.5mm
1/4-20 THREAD
5.1
2.00
0.52
25.4
50.0mm
225.0mm
3.26
1.00
9.00
0.20
0.25[6.4]
18.3mm
2X 0.129
2.80 71.1
4411-0139_0149
