NOTES:
1. MOUNTING FACE TO IMAGE PLANE IS FACTORY PRESET
TO OPTICAL DISTANCE OF 0.894± 0.010 [ 22.71 ± 0.25]
2. MOUNTING FLANGE ORIENTATION CAN BE ROTATED
IN 180 INCREMENTS
REMOVABLE EXTENDER BRACKET
2X 0.129 [3.3 ] HOLES
1/4-20 THREAD
M6x1.0 THREAD
1/4-20 THREAD
1.00 25.4
50.0mm
2.00
225.0mm
9.00
0.71
23.1mm
0.20 5.1
AIR EXHAUST
AIR INTAKE
MOUNTING FACE
SEE NOTE 1.
9.20±0.03 233.6±0.8
1.71
1.24
INTENSIFIER DEPENDANT
43.4
31.5
4.25 108.0
2.60 66.
0
0.06 1.5
1.10 27.9
AIR INTAKE
CATHODE COOLING INPUT
3X #10-32 THREAD
ON
3.88 BOLT CIRCLE
SEE NOTE 2.
3X 0.20 5.2 RADIAL SLOT
ON
3.60 BOLT CIRCLE
SEE NOTE 2.
4.50 114.3
4.50 114.3
1.94
49.3
3. DIMENSIONS IN INCHES [mm]
4. TOLERANCES: ± 0.01 [± 0.25]
5. WEIGHT: CAMERA 7 lbs (3.2 kg)
POWER SUPPLY 4.1 lbs (1.87 kg)
