Princeton Instruments PI-MAX4 - Appendix C: WinX;LightField Cross Reference; C.1 WinX-to-LightField Terminology

287
Appendix C: WinX/LightField Cross
Reference
This appendix provides cross reference information for terminology used within the WinX
and LightField application software packages.
C.1 WinX-to-LightField Terminology
Refer to Table C-1 for a list of WinX terms and their corresponding LightField terms.
Table C-1: WinX-to-LightField Cross Reference (Sheet 1 of 2)
WinX Term LightField Term
Active Rows Parallel to Shift Register Active Height
Active Shift Register Columns Active Width
ADC Rate Speed
ADC Resolution Bit Depth
Continuous Cleans Clean Until Trigger
Controller Gain Analog Gain
Custom Chip Custom Sensor
Custom Timing Custom Timing
Disabled Closed (Shutter) Always Closed (Shutter)
Disabled Open (Shutter) Always Open (Shutter)
Dual Trigger Mode Shift Per Trigger
Easy Bin Sensor Readout Region expander functions
Edge Trigger Trigger Determined By
External Sync Readout Per Trigger
F.T. Dummies or Frame Transfer Dummies Active Area: Top Margin
Focus Preview or Run
Free Run No Response
Logic Out Output Signal
Logic Out: Logic 0 Output Signal: Always Low
Logic Out: Logic 1 Output Signal: Always High
Logic Out: Not Ready Output Signal: Busy
Logic Out: Not Scan Output Signal: Not Reading Out
