120 Cabling
Figure 13 Example of LTO-5 Drives Connected to Ethernet Expansion Blades
LTO-5 Drive
1,1,1,1,1,1
1,1,1,2,1,1
1,1,1,3,1,1
1,1,1,4,1,1
1,1,1,5,1,1
1,1,1,6,1,1
1,1,1,7,1,1
1,1,1,8,1,1
1,1,1,9,1,1
1,1,1,10,1,1
1,1,1,11,1,1
1,1,1,12,1,1
EEB port connection
