Scalar i6000 Installation Guide 167
The Cycle button enables you to cycle the external Ethernet interface without rebooting the library.
1 Make the appropriate network configuration changes, and then click OK.
2 A prompt appears that informs you that network connectivity will be temporarily lost and asks whether
you want to proceed. click Yes.
Proceed to Setting Date and Time
on page 169.
Setting up IPv6 Network Configuration
After completing steps one through 3 of Setting Up the Network Configuration on page 165, the Static IP
tab of the IPv6 Network Configuration dialog box appears.
1 Use the Static IP tab to disable or to enable and specify a static IP address. Valid static IP addresses
include link local, site local, and global unicast.
2 To display the DHCP tab, click DHCP.
3 As prompted, use the DHCP tab to enable or disable the Dynamic Host Configuration Protocol (DHCP)
autoconfiguration function.
In the Port Settings area:
Auto Negotiate Select Enable to have the library automatically negotiate port speeds. Enable
makes the Speed options unavailable. Select Disable to make the Speed
options available for you to manually set the port speed.
Speed The port speed (10 Mbps or 100 Mbps). Speed options are available only if Auto
Negotiate is disabled.
Element Description
