194 Configuring the Library
The Partition Details dialog box appears. This windows shows additional information about the
partition, such as vendor, product ID, and serial number.
4 Click Close to close the Partition Details dialog box.
5 Click Close to close the Partitions Status dialog box.
Proceed to Configuring FC I/O Blade Ports
on page 194.
Configuring FC I/O Blade Ports
Each FC I/O blade installed in the library has two ports reserved for connection to hosts or the SAN. These
ports are FC-1 and FC-2. By default, ports FC-1 and FC-2 are in target mode. The other four ports (FC-3,
FC-4, FC-5, and FC-6) are in initiator mode by default.
The default FC I/O blade ports are given in Table 9
on page 194.
Table 9 FC I/O Blade Default Port Settings
Port Loop ID Speed Frame Size Port Mode
Connection
Option
Private/Public
FC-1 Soft Auto 2048 Target Loop preferred Public
FC-2 Soft Auto 2048 Target Loop preferred Public
FC-3 Soft Auto 2048 Initiator Loop preferred Public
FC-4 Soft Auto 2048 Initiator Loop preferred Public
FC-5 Soft Auto 2048 Initiator Loop preferred Public
FC-6 Soft Auto 2048 Initiator Loop preferred Public
