Quantum Scalar i6000 - Assembling the Last Expansion Module

70 Installing a Multi-Module Library
Assembling the Last Expansion Module
Required tools: 2.5 mm hex wrench,
1 Remove the magazine storage on rack # 1 in sections 1 - 5 on Column 4 in the last expansion module.
drive cluster
top view of module
rack 1 (back)
rack 2 (front)
column 4
section 1
section 2
section 3
section 4
section 5
rack 1 (back)
drive cluster
