Scalar i6000 Installation Guide 25

Setting the Leg Lock Nuts

Required tools: 24 mm open end wrench

1 Verify that all four leveling legs are carrying load and that the control module does not rock.

2 Use the 24 mm open end wrench to raise the four leveling leg lock nuts to the top and tighten them

against the welded nut.

Note

Ensure that you do not take the leveling legs out of adjustment during this

process.
