Scalar i2000 Installation Guide 287
17 If there is an expansion module immediately to the right of the expansion module you are upgrading,
open its access door for clearance.
18 To avoid scratching the new access door on the door latches of the expansion module to the right, use
a 3 mm hex wrench to remove the four door latches.
top latches
bottom latches
