Scalar i6000 Installation Guide 29
3 Tighten the bolts using the 6 mm hex wrench and the 13 mm open end wrench.
4 Once the frames are aligned and bolted properly together, proceed to Pos
itioning the System Unit on
page 30.
Note
Do not overtighten the bolts. Overtightening can damage the vertical frame
post structure.
front upper bolt
front lower bolt
back upper bolt
back lower bolt
